QSC TouchMix-8 Compact Digital Mixer with Touchscreen

The QSC TouchMix Series represents a breakthrough in innovation and digital mixer design – the result of a remarkable collaboration between QSC and industry icons Greg Mackie and Peter Watts (M&W Pro Audio Ltd.) TouchMix not only resets the bar for performance and value, but also redefines the user experience for both professionals and novices alike.

Shipping & Delivery

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

  • DHL Courier delivery

DHL courier will deliver to the specified address

1-3 Days

Free

  • Warranty 1 year
  • Free 30-Day returns

Description

The QSC TouchMix-8 compact digital mixer is designed for musicians, production professionals and live performance venues that need the power and capability of a large “concert” mixing console in a compact, affordable and easy to use form. TouchMix-8 mixers have the functionality to satisfy demanding professionals combined with a range of features and functions that help the less experienced user achieve quality results.

Simple Mode makes getting great results easy and fast (similar to the “Auto” function on a DSLR camera. Advanced Mode gives pro users total control over all mixer parameters. Wizards and preset libraries created specifically for live sound reinforcement assist the user with channel setup, effects selection and more. The built-in colour touchscreen combines with hardware controls for fast and intuitive operation “Big Mixer” Features and Specifications. Includes gate, compressor, 4-band full parametric EQ and variable high-pass filter on all input channels.

The TouchMix-8 includes four premium stereo DSP’s with a full selection of professional digital effects, 1/3 octave graphic EQ, notch filters, limiters and delay on main and aux. Channel-selectable phantom power is available on the unit’s high quality microphone preamps. Multiple monitor mixes including the ability to drive in-ears directly.

This unit can be operated via the internal colour touch-screen and rotary dial, a mobile device or both simultaneously. A USB Wi-Fi adapter is included, and no additional network hardware is required for remote control.

Multitrack direct to disk recording/playback is available via an external USB hard drive (not included) with no computer required. The Touchmix is approximately the size and weight of a small laptop computer and a padded carrying case is included for protection and easy transport.

TouchMix delivers all the processing power and features that a professional live sound engineer could want!

Features

  • 12 total inputs: 8 mic, (four with XLR/TRS combo connector) and two stereo line
  • Superb sound quality
  • Class-A microphone pre-amps
  • 32-bit floating point processing
  • 24-bit AD & DA convertors
  • Four-band full parametric EQ
  • Variable high-cut and low-cut filters
  • Gate, Compressor (with de-esser)
  • Four professional quality stereo DSP effects
  • A pitch correct processor is assignable to any input channel
  • Great results and easy to use
  • Input channel preset library features over 100 presets
  • Wizards assist with input gain adjustment and effects selection and routing
  • Record 14 tracks (all inputs plus a stereo mix) directly to USB hard-drive
  • Remote control via iPad®
  • USB Wi-Fi interface and carrying case are included

More Than Sound – It’s an Experience. Audio Shop Australia.

More Than Sound – It’s an Experience. Audio Shop Australia.

About brand

QSC is a leading name in professional audio, delivering premium-quality sound systems, digital mixers, power amplifiers, and loudspeakers. Known for their innovation and durability, QSC products are trusted by musicians, DJs, sound engineers, and venues worldwide. Whether you're building a live performance setup, a studio, or an event rig, QSC offers unmatched reliability and performance.

At Audio Shop Australia, you’ll find a wide range of QSC audio solutions designed for powerful sound clarity and long-lasting use—perfect for both touring professionals and sound enthusiasts.

Tech Specs
Key Specs
Max I/O Capacity
14x Input / 8x Output
Number of Analog Input Channels
10 (8 Mono / 2 Stereo)
Number of Mic Preamps
8
Number of Analog Output Channels
8
Faders & Level Adjustment
No
Built-In Effects
Reverb
Echo (Type Unspecified)
Delay
Chorus
1x Pitch Correct
50x Preset (Factory)
50x Preset (User)

Analog Inputs
4x Combo XLR-1/4" TRS Mic/Line Input
4x XLR Mic Input
2x 1/4" TRS Line Input (2 Stereo Pairs)
Analog Outputs
2x XLR Main/Line Output
4x XLR Line/Aux Output
1x 1/4" TRS Stereo Monitor Output
1x 1/4" TRS Headphone Output

Digital I/O
No
USB I/O
1x USB-A (Multitrack Record)
1x USB-A (Wi-Fi)
Wireless
Wi-Fi
Rack Mountable
No
Mixer
Max I/O Capacity
14x Input / 8x Output
Number of Analog Input Channels
10 (8 Mono / 2 Stereo)
Number of Mic Preamps
8
Number of Analog Output Channels
8
Mix Routing
6x Mono Matrix
Groups
8x DCA Group
8x Mute Group
Presets
120x Preset (Factory)
Display
7" LCD Touchscreen (Backlit)
Faders & Level Adjustment
No
Signal Processing
Dynamic Processing
Input Channels:
Compressor, Gate
Buses, Master:
Limiter
EQ
Input Channels:
4-Band Parametric/Shelving
Outputs, Subgroups:
9-Band Graphic
Subgroups:
4-Band Parametric
FX Returns, USB:
2-Band Shelving
Graphic EQ
No
Filters
Input Channels:
High-Pass , 24 dB/Octave
Low-Pass , 24 dB/Octave
FX Returns, USB:
High-Pass , 24 dB/Octave
Master, Buses:
High-Pass
Low-Pass
4x Notch
Solo/Mute
Solo-in-Place/AFL per Input Channel
Built-In Effects
Reverb
Echo (Type Unspecified)
Delay
Chorus
1x Pitch Correct
50x Preset (Factory)
50x Preset (User)
Audio Delay
No
Automatic Mic Mixing
No
Digital Audio
Sample Rates
44.1 / 48 kHz
Performance
Frequency Response
20 Hz to 20 kHz ±0.5 dB
Max Input Level
Mic Input:
+16 dB
Line Input:
+22 dB
Analog Dynamic Range
105 dB
Noise Floor
-86 dBu
SNR
-94 dB
Signal Generator
No
Connectivity
Analog Inputs
4x Combo XLR-1/4" TRS Mic/Line Input
4x XLR Mic Input
2x 1/4" TRS Line Input (2 Stereo Pairs)
Analog Outputs
2x XLR Main/Line Output
4x XLR Line/Aux Output
1x 1/4" TRS Stereo Monitor Output
1x 1/4" TRS Headphone Output
Phantom Power
+48 V (Selectable on Individual Inputs)
Digital I/O
No
MIDI I/O
No
USB I/O
1x USB-A (Multitrack Record)
1x USB-A (Wi-Fi)
USB I/O Capacity
2x Input / 2x Output
Expansion Ports
No
Wireless
Wi-Fi
Recording
Max Multitrack Recording
14 Tracks
Media Support
HDD
Power
Input Power
100 to 240 VAC, 50 / 60 Hz
Physical
Rack Mountable
No
Dimensions
3.1 x 3.1 x 9.8" / 79 x 333 x 250 mm
Weight
4.3 lb / 1.9 kg
Packaging Info
Package Weight
10.4 lb
Box Dimensions (LxWxH)
20 x 16 x 5"
